Dedicated to hand held electro therapy devices.
Point Stimulator/Locators.
Laser Therapy Units.

Pointer Pulse™
The next generation handheld locator/stimulator! The Pointer Pulse is the first
all-in-one unit that combines laser therapy with electrical stimulation,
allowing both methods of treatment to be used simultaneously or separately.
The device measures relative skin resistance at the treatment location through
sound as well as a green light indicator found on the top of the unit. Location
sensitivity and sound level are adjustable.
An effective push button adjustable stimulation offers immediate treatment.
Based on the setting of the output dial, either milliamp or micro amp current
output is produced (i.e., blue zone on the dial is milliamp).
Laser therapy is administered using a 650 nm, 5 mW laser contained in the
device. Three modes of treatment are available, selected by using a toggle
switch located between the grounding plate and stimulation button: on
(continuous laser beam), pulsed (10 Hz pulsed laser beam) and off (no laser
beam). The device is successfully in laser mode when the yellow light indicator
on the top of the unit is on.
With its ergonomic design and single grounding plate, this device can easily be
used with either the left or right hand. Probe tip is removable for easy
cleaning. Accessories include a hand ground pole with attached wire, 9-volt
battery, small screwdriver (for adjusting sound level), carrying case, and
instructions. There is a 1-year warranty on this device.
Note: Conductive gel may clog laser probe opening and diminish
output. Use of gel with this device is not recommended.

|
Specifications |
500 ohm test load |
|
Output channels |
One |
|
Volts & current |
|
|
Normal dial |
22.5 volts, 0 to 45 milli amps |
|
Blue zone |
11.0 volts, 0 to 2 micro amps |
|
Pulse width |
260 microseconds (µS) |
|
Pulse shape |
Asymmetric biphasic square wave with negative spike |
|
Pulse modes |
Continuous |
|
Laser wavelength |
650 nm |
|
Maximum laser power |
5 mW |
|
Skin impedance monitoring |
Sound and green light indication |
|
Laser operation |
Yellow light indication |
|
Power source |
9 volt battery |
|
Size, wt, color |
9.0" x 3.5" x 1", 100gm, beige |
The Pointer Pulse On Sale Now! $ 224.95
